    Suitable for Napoli Pans (accessory)

  • product-20306-detailimage2

    Curved glass for nice presentation

  • product-20306-imagerange
  • product-20306-webprimaryimage
  • product-20306-primaryimagenoshadow
  • product-20306-detailimage1
  • product-20306-detailimage2
  • product-20306-imagerange

Scoop Ice Cream Display

ISABELLA 10LX

Item no.: 20306

  • Fully automatic
  • Curved glass canopy
  • Accepts Napoli pans (not supplied)
  • Static cooling
  • LED interior light with switch
  • Easy access understorage
  • Digital controller and temperature display
  • Rear night curtain to maintain temperature
  • Castors

Technical specifications

Measures and Content

  • Total Display Area
    0.59
  • Temperature Range
    -16 to -14 °C
  • Climate Class
    4
  • Gross / Net Weight
    155 / 132 kg
  • Serving Capacity
    10 Napoli Pans (5 L )
  • Storage capacity (under)
    10 Napoli pans (5 L)

Design and Material

  • Exterior Finish
    Grey
  • Interior Finish
    White
  • Interior Light
    LED

Cooling and Functions

  • Type of Controller
    Electronic
  • Type of Cooling
    Static
  • Type of Defrost
    Automatic, hot gas
  • Refrigerant
    R290
  • Refrigerant Charge
    120 g
  • Thermometer

Power and Consumption

  • Energy Class
    C
  • Max Ambient
    30°C at 55% RH
  • Energy Consumption
    9.6 kWh/24h
  • Annual Energy Consumption
    3504 kWh/year
  • Input Power
    550 W
  • Voltage / Frequency
    220-240/50 V/Hz
  • Noise Level
    54 dB(A)

Dimensions

  • External Dimension (WxDxH)
    1317 x 906 x 1372 mm
  • Packed Dimension (WxDxH)
    1418 x 978 x 1450 mm
  • 40ft Container Load
    16 pcs
  • GTIN / EAN
    7025101021004
  • Product Group - Delivery services
    Group 2

Downloads

Description

10 scoop static cooled display with understorage

The Isabella range is a spacious ice cream scooping cabinet with 10 or 13 pan options. Its curved glass design makes for an eye catching display that is sure to delight your customers, and the rear serving shelf helps aid with fast service. With built-in refrigerated under storage, you can easily restock the display with fresh ice cream during busy periods without having to leave the cabinet. Additionally, the cabinet comes with castors for easy manoeuvrability and an internal LED light to showcase your gelato or ice cream in the best possible light.
