Divider as option
Well suited for graphics
Impulse Can Cooler
VOC100
Item no.: 20010
- Fully automatic
- Fan assisted cooling
- LED canopy light
- Adjustable feet
- Digital controller and temperature display
- Next day delivery available on product
- Unpack & Position£ 37.00
- Remove & Dispose£ 67.00
Check Delivery Options and Services
Technical specifications
Measures and Content
- Cans 330 ml80 pcs
- Cans 500 ml50 pcs
- Bottles 330 ml50 pcs
- Bottles 500 ml PET50 pcs
- Total Display Area0.75 m²
- Temperature Range+2 to +12 °C
- Climate Class4
- Gross / Net Weight31 / 29 kg
- Gross / Net Volume110 / 103 l
Design and Material
- Feet / Legs7 gliding feet
- Exterior FinishGrey
- Interior FinishGrey
- Interior LightLED
Cooling and Functions
- Type of ControllerElectronic
- Type of CoolingVentilated
- Type of DefrostOff Cycle
- RefrigerantR600a
- Refrigerant Charge55 g
- Thermometer
Power and Consumption
- Energy ClassD
- Max Ambient30°C at 55% RH
- Energy Consumption2.6 kWh/24h
- Annual Energy Consumption949 kWh/year
- Power13 Amp
- Input Power160 W
- Voltage / Frequency220-240/50 V/Hz
- Noise Level42 dB(A)
Dimensions
- Internal Dimension (WxDxH)520 x 345 x 570 mm
- External Dimension (WxDxH)660 x 460 x 970 mm
- Packed Dimension (WxDxH)700 x 500 x 1150 mm
- 40ft Container Load 128 pcs
- GTIN / EAN5708181001117
- Product Group - Delivery servicesGroup 1
Downloads
Description
Spare parts
- 01Item no. 11131Inner Lexan 1 mm
- 02Item no. 11192Outer Lexan 1 mm
- 03Item no. 10369Air Conductor Grey
- 04Item no. 15773Insulation Material
- 05Item no. 10794Base Plate
- 06Item no. 10773Back Panel Grey
- 07Item no. 10857Bottom Panel Grey 345 mm
- 08Item no. 10795Base Spacers
- 09Item no. 10922Compressor Base Plate
- 10Item no. 14590Gliding Shoe
- 10
Item no. 14677Wheel Without Brake - 11Item no. 10285Canopy Plate
- 12
Item no. 11291Top Frame - 13Item no. 10791Base For Top Frame
- 14
Item no. 13969Thermostat Carel PYSN0V00115 - 14
Item no. 14060Thermostat XR02CX 2 Probe Blue - 15
Item no. 15650LED Strip 580 mm 7000K/7LM - 16
Item no. 15612LED Power Supply - 17Item no. 14860Base Shelf Grey
- 18Item no. 11213Profile For Lexan
- 19Item no. 14445Evaporator House
- 20Item no. 14453Evaporator Polystyrene
- 21
Item no. 14239Evaporator - 22Item no. 14423Evaporator Cover Polystyrene
- 23Item no. 14424Evaporator Cover Sheet
- 24Item no. 11727Compressor HMK12AA R600
- 25
Item no. 15729Filter Drier 7.5 G - 26
Item no. 13896Probe NTC Dixell/Carel 10 Kohm - 28Item no. 11436Drain Hose
- 29Item no. 13530Fan Motor Foot
- 30
Item no. 13519Fan Motor - 31
Item no. 13483Fan Blade 200 mm - 32
Item no. 13577Inner Fan - 33
Item no. 14091Condenser - 34
Item no. 15515Holder For LED Strip - 35
Item no. 14777Divider Grey RAL 9006 - 36Item no. 14742Base Shelf For Dividers Black
- 36Item no. 14743Base Shelf For Dividers Grey
- 36Item no. 14744Base Shelf For Dividers White
- 37Item no. 14822Small Divider Black
- 37Item no. 14823Small Divider Grey
- 37Item no. 14824Small Divider White
- 38Item no. 14746Big Divider Black
- 38Item no. 14747Big Divider Grey
- 38Item no. 14748Big Divider White
- 99Item no. 38401LED Light Curved 2700K 6,48 W
